C4h-2Deck/C4h-3Deck
Keestrack C4 is available as a – 2 or 3 deck Classifier
Enquire about this equipment
Contact us-
Performance highlights
- Compact high production classifier – 3 & 4 split
- Double or Triple deck screen box 3.600 x 1.500 mm (12’ x 5’)
- Fuel-saving load sense piston pump technology
- Auto sequential start as standard
- True mobility, no support legs under feed hopper
- All decks are interchangeable
- Capacity up to 400 tonnes/hour
- 5,4 m² screening surface on each deck
- Feed hopper 8 m³ (10 yard³)
- low emission engine
- Interchangeable screen meshes on all decks
- 2-speed track drive
-
Applications
- Quarrying 0-4, 4-8, 8-16, 16-32, and others as specified
- Sand and gravel
- Separation of aggregate
- Construction and demolition
- Screening behind a crusher
- Coal and others
-
Specification
Transport dimensions 2 Deck Transport dimensions 3 Deck Working Dimensions 3 Deck Weight 25 t (27 sT) 28 t (30 sT) Length 13.700 mm (44’11”) 13.700 mm (44’11”) 15.850 mm (52’) Height 3.150 mm (10’4”) 3.325 mm (10’11”) 4.240 mm (13’11”) Width 2.550 mm (8’4”) 2.800 mm (9’2”) 14.400 mm (47’3”)
