Performance highlights
- Available in a full hybrid version
- High production screen box, upper deck screening fraction up to 200 mm
- Capacity up to 1.000 tonnes/hour
- Electric, energy-saving, a full hybrid version
- Feed hopper 8 m³ (10 yard³), several hopper extensions available
- Large range of screen meshes, fingers, punched plate, grizzly & rubber decks available
- 2-speed track drive
- Extensive option list to configure to your application
-
Applications
- Pre-screening/scalping
- Screening heavy over-burden
- Recycling landfill and construction waste
- Separation of “sticky” aggregate
- Construction and demolition
- Screening behind or before a crusher
- Quarrying and mining
- Coal
- Armourstone and others
-
Specifications
Transport dimensions Working dimensions Weight 32 t (35 sT) Length 13.360 mm (43’10”) 15.400 mm (50’6”) Height 3.380 mm (11’1”) 3.700 mm (12’2”) Width 2.720 mm (8’10”) 14.400 mm (47’3”)
