Performance highlights
- Very good stockpiling capabilities
- 75% cost-saving capacity compared to a loading shovel
- Main conveyor 800 mm (31”) wide, 18 meter (59’) long
- Feed capacity up to 250 tonnes an hour
- Available in full hybrid version
- Stockpile capacity from 1.200 tonnes to 7.500 tonnes
- Discharge height from 6,7 meter (22’) to 7,8 meter (25’)
- Available in Diesel/Hydraulic drive, Diesel/Electric drive
-
Applications
- Stockpiling
- Transport
- Loading
- Sorting and others
-
Specifications
Transport dimensions Weight 10,3 t (11 sT) Length 11.900 mm (39’) Height 2.330 mm (7’8”) Width 2.290 mm (7’7”)
