Applications
- Limestone and many other natural rocks
- Concrete and landfill recycling
- Primary and secondary crushing
- Yard clean up
- Construction waste
- Demolition
- Quarrying and mining
- Gravel
- Asphalt
- Coal and others
-
Performance highlights
- Hopper 5 m³ (6,5 yard³)
- Independent 2-deck pre-screen 2.200 x 1.000 mm (7’ x 3’)
- Due to long pre-screen, higher crushing capacities, and less wear
- Inlet opening (H x W) 800 x 1.050 mm (31” x 41”)
- Rotor diameter 1.260 mm (50”), rotor width 1.000 mm (39”)
- Swiveling oversize return conveyor/stockpile conveyor
- Optional single deck after screen 3.300 x 1.500 mm (11’ x 5’), 4,95 m²
- Optional double-deck after screen
- Also available in Electric version with electric driven Rotor and plug-in / plug-out functionality
- Tilting chassis
- Capacity up to 350 tonnes/hour
- Load sensing hydraulic system reduces fuel usage by 25%
- 2-speed track drive
- Highest reduction ratio
- Superior product shape
- Extensive option list to configure to your application
- Optional wind sifter
-
Specifications
Transport dimensions Transport dimensions with after screen working Working length without after screen working Working length with after screen Weight 42,5t (46 sT) 50 t (55 sT) Length 14.700 mm (48’4”) 16.860 mm (54’9”) /17.400 mm (57’1″) 14.530 mm (47’8”) 19.000 mm (62’4”) Height 3.490 mm (11’5”) 3.490 mm (11’5”) Width 3.000 mm (9’10”) 3.000 mm (9’10”)
